DC Parameters

Battery Type

LFP

Operating Voltage Range

650V～949V

Combination Mode

1P260S

Cooling Mode

Liquid cooling

Rated Capacity

314Ah

Coolant

Ethylene glycol solution (50% v)

Rated Energy Capacity

261kWh, 25℃@0.5CRated

Cycle Life

8000

Rated Voltage

832V

Fire Protection System

Perfluorohexanone + Aerosol +
Water fire suppression

Maximum Charging/Discharging Power

125kW

Detector Type

Temperature, smoke, CO

Rated Charge/Discharge C-rate

0.5P

AC Parameters

Rated Output Power

125kW

AC Overload Capability

137.5kW

Wiring Method

Three-phase, four-wire

Allowed Grid Voltage

380V/400V（-15%～＋15%）

Allowed Grid Frequency

50Hz/60Hz±2.5Hz

Maximum Output Current

150A

Total Harmonic Distortion (THD)

≤ 3% (at full load)

Power Factor

-0.99/-1~1

DC Component in Current

≤0.5%

Charge/ Discharge Conversion Time

＜100ms

Maximum Conversion Efficiency

≥98％

System Parameters

Operating Environment

-20°C to 50°C (de-rated operation above 45°C)

Noise Level

≤75dB

Dimensions

1000*1300*2500mm

Weight

~2.6 tons

Water Resistance Rating

Battery compartment: IP65, Electrical compartment: IP54

Allowed Relative Humidity

0-95% (non-condensing)

Maximum Altitude

≤ 2000m (de-rating above 2000m)

Communication Interface

CAN, Ethernet

Communication Protocol

Modbus TCP/ RTU

System Operation Mode

Peak shaving, demand control, reactive power adjustment,
grid scheduling interface,Remote dispatch, local data storage, anti-backflow feature

Certification Standards

GB/T36276-2018
