Model

72kwh-50K

86kwh-50K

100kwh-50K

Battery

Battery Type

LiFePO4

Battery Capacity

280Ah

Pack Configuration

1P16S*5

1P16S*6

1P16S*7

Nominal Capacity

71.68kWh

86.016kWh

100.352kWh

Nominal Voltage

256V

307.2V

358.4V

Operating Voltage Range

224~284V

268.8~304.8V

313.6~397.6V

Max.Continuous Charge / Discharge Current

140A

Charge / Discharge Rate

0.5C

Cycle Life

Cyde Life ≥6000 /5 Years (@25°C ±2°C, 0.5C /0.5C,70% EOL )

PV

Max.DC Input Voltage

1000V

MPPT Voltage Range

200~850V

DC Inputs

2/2/2/2

Max. lnput Current

40A*4

Back-up

Rated Output Power

50kW

On/ Off-grid Switching Time

＜10ms

Peak Output Apparent Power

1.5 Times Of Rated Output Power, 10s

Syetem

Max. AC Output Power

55kW

Grid Type

3L/N/ PE

AC Output Frequency

50160HZ

AC Output Voltage

400±5%V

Voltage Harmonic Distorion

＜3% @Linear Load

AC Max. Output Current

83A

Power Factor

0.8 Leading... ..8 Lagging

Ingress Protection

IP54

Anti-Corrosion Grade

C3 (C4 Optional)

Max. System Efficiency

88%

Charge Operating Temperature

0°C~45°℃

Discharge Operating Temperature

-20°C~50°℃

Operating Temperature Range

-20°C~50°℃

Relative Humidity

5~95 %(non-condensing)

Max. Working Alitude

3000( >2000m derafing)

Communication

CAN/RS485/ WIFi/LAN (Optional )

Cooling

Air Cooling

Dimension

1150 × (1325±5) × 2280 mm

Net Weight

≤1140kg

≤1240kg

≤1340kg

Max. Parallel

5
