MODEL

10K-UP

   8K-UP

Can Be Set

INVERTER OUTPUT

Rated Output Power

10,000W

8,000W

Max. Peak Power

20,000W

16,000W

Rated Output Voltage

120Vac，single-phase / 240Vac，split-phase/three-phase, be paralleled

√

Load Capacity of Motors

6HP

5HP

Rated AC Frequency

50/60Hz

√

Waveform

Pure sine wave

Switch Time

10ms (typical)

Parallel Capacity

1~6 units

Output Mode

Off-grid (default) / Hybrid

√

BATTERY

Battery Type

Li-ion / Lead-acid / User-defined

√

Rated Battery Voltage

48Vd

Battery Voltage Range

40～60Vdc

√

Max. MPPT Charging Current

200A

180A

√

Max. Mains / Generator

120A

100A

√

Charging Current

Max. Hybrid Charging Current

200A

180A

√

PV INPUT

Num. of MPPT Trackers

2

Max. PV Array Power

5,500W+5,500W

Max. Input Current

22A+22A

Max. Open Circuit Voltage

500Vdc+500Vdc

MPPT Voltage Range

125～425Vdc

UTILITY / GENERATOR INPUT

Input Voltage Range

90～140Vac

√

Frequency Range

50/60Hz

Bypass Overload Current

63A

EFFICIENCY

MPPT Tracking Efficiency

99.90%

Max. Battery Inverter Efficiency

92%

GENERAL

Dimensions

620*445*130mm

Weight

27kg

Protection Degree

IP20，indoor only

Operating Temperature Range

-10~55℃, >45℃ derated

Noise

<60dB

Cooling Method

Internal Fan

Warranty

18 Months

COMMUNICATION

Embedded Interfaces

RS485 / CAN / USB / Dry contact

√

External Modules (Optional)

Wi-Fi / GPRS

√

CERTIFICATION

Safety

IEC62109-1, IEC62109-2, UL1741

EMC

EN61000-6-1, EN61000-6-3, FCC 15 class B
