Model

SUN-10K-SG02 LP1-EU-AM3

SUN-12K-SG02 LP1-EU-AM3

SUN-16K-SG01LP1-EU

SUN-18K-SG01LP1-EU-AM3

Battery Input Data

Battery Type

Lead-acid or Lithium-ion

Battery Voltage Range (V)

40-60

Max. Charging Current (A)

220

250

290

350

Max. Discharging Current (A)

220

250

290

350

Charging Curve

3 Stages / Equalization

Charging Strategy for Li-Ion Battery

Self-adaption to BMS

PV String Input Data

Max. DC Input Power (W)

13000

15600

20800

28800

Rated PV Input Voltage (V)

370 (125-500)

370

Start-up Voltage (V)

125

MPPT Range (V)

150-425

PV Input Current (A)

26+26+26

36+36+36

Max. PV I (A)

44+44+44

54+54+ 54

No.of MPP Trackers

3

No.of Strings per MPP Tracker

2+2+2

AC Output Data

Rated AC Output Active Power (W)

10000

12000

16000

18000

Max AC Output Active Power (W

11000

13200

17600

19800

Rated AC Output Current (A)

45.4/43.5

54.6/52.2

72.7/69.6

81.9/78.3

Max AC Output Current (A)

50/47.9

60/57.4

80/76.5

90/86.1

Max. Continuous AC Passthrough (A)

60

100

200

Peak Power (Off Grid)

2 time of rated power, 10 S

Power Factor Adjustment Range

0.8 leading to 0.8 lagging

Output Frequency and Voltage

50Hz/45Hz-55Hz 60Hz/55Hz-65Hz

Grid Type

single phase

Total Harmonic Distortion (THD)

<3%(of nomial power)

DC Current Injection

<0.5%

Efficiency

Max. Efficiency

97.60%

97.6%

97.6%

Euro Efficiency

97.00%

96.5%

96.5%

MPPT Efficiency

99.90%

99.90%

>99%

Protection

Integrated

Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge Protection

Over Voltage Category

DC Type II/AC Type III

Certifications and Standards

Grid Regulation

VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150

Safety EMC / Standard

IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

General Data

Operating Temperature Range (℃)

-40 to +60℃, >45℃ Derating

Cooling

Smart Cooling

Noise (dB)

≤30 dB

Communication with BMS

RS485; CAN

Weight (kg)

32

48.5

48.5

Cabinet Size (WxHxD mm)

420×670×233

464×763×282

464×863×282

Protection Degree

IP65

Installation Style

Wall-mounted

Warranty

5 Years/10 Years the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
