Datasheet

Growatt SPF 3500 ES

Growatt SPF 5000ES

Growatt SPF 6000ES PLUS

Battery Voltage

48VDC

Battery

Lithium/Lead-acid

             Inverter Output

Rated Power

3500VA/ 3500W

5000VA/ 5000W

6000VA/6000W

Parallel Capability

Yes, 6 units maximum

AC Voltage

230VAC ± 5% @ 50/60Hz

Surge Power

7000VA

10000VA

12000VA

Efficiency (Peak)

93%

Waveform

Pure sine wave

Transfer Time

10ms typical, 20ms Max

              Solar Charger

Maximum PV Array Power

4500W

6000W

8000W

MPPT Range

120VDC ~ 430VDC

120VDC ~ 450VDC

MPP Trackers

1/1

2/1

               Ac Charger

Charge Current

60A

80A

80A

AC Input Voltage

230 VAC

Frequency Range

50Hz/60Hz (Auto sensing)

                Physical

Protection Degree

IP20

Dimension (W/H/D)

330/485/135mm

330/485/135mm

460/395/132mm

Net Weight

11.5kgs

12kgs

13.5kg
